Mini Itx con 780G e 8200

[robbynaish]

Ciao,

aspettavo con ansia questa tipologia di schede, per provare ad assemblare un ottimo HTPC formato miniMac...
Oltreoceano stanno uscendo, e le piu gettonate sono queste 3, oltre ad una Cinese J&W che però è difficilissima da trovare... (ha anche slot dimm per la Gpu 780G!!!!)

Jetway NC 81




CPU
Socket AM2 HT 3.0 AMD® Opteron™ With Hyper Transport Technology
Compatible with 64-bit Dual Core AMD® Athlon™64 X2 Processors

Chipset
AMD 780G Chipset + SB700 Chipset

Memory
2 * SODIMM Sockets for un-buffered Dual Channel DDR2 800 SDRAM up to 4 GB

Expansion Slots
1 * 32-bit PCI slots

Storage
Embedded SB700 Chipset

4 * Serial ATA2 3Gb/s connectors
Supports HDDs with RAID 0, 1,10 functions
1 * Ultra DMA 133 / 100 / 66 IDE connector

Audio
Realtek ALC883 6-Channel HD Audio CODEC w/ SPIF in and out

Ethernet LAN
Realtek RTL8111C PCI LAN chip for Gigabit Ethernet LAN
Realtek RTL8111C PCI-E LAN chip for Gigabit Ethernet LAN

USB
Embedded 8 * USB 2.0/1.1

Special Features
Advanced Power Design that supports the latest Socket-AM2+ CPU
¡§IMAGE IT!¡¨ System Backup Software and ¡§ProMagicPLUS!¡¨ System Recovery System

Rear Panel I / O
4 * USB 2.0/1.1 ports
2 * RJ-45 ports & 2 * e-SATA ports
1 * Audio I / O ports
1 * VGA port
1 * DVI port
1 * HDMI port

Internal I / O
2 * USB 2.0/1.1 headers for 4 USB 2.0 ports
CPU / Chassis Fan connectors;
1 * 4-pin ATX 12V Power connector and 1 * 20-pin ATX Power connector
1 * COM header & 1 * Serial Port header & 1 *12-PIN Wi-Fi header

BIOS
Award 8MB SPI Flash ROM

Form Factor
Mini ITX Form Factor(17cmx17cm)



Jetway NC62K




CPU
Socket AM2 HTT 3000 MHz AMD® Opteron™ With Hyper Transport Technology
Compatible with 64-bit Dual Core AMD® Athlon™64 X2 Processors
Suggest CPU power consumption <= 65W

Chipset
NVIDIA GF-8200 (MCP78S) single chipset

Memory
1*240-pin DIMM Sockets for un-buffered Single Channel DDR2 1066/800 SDRAM up to 2 GB

Expansion Slots
1 * 32-bit PCI slots

Storage
Embedded MCP78S Chipset

4 * Serial ATA2 3Gb/s connectors
Supports HDDs with RAID 0, 1, 0+1, 5,JBOD functions
1 * Ultra DMA 133 / 100 / 66 IDE connector

Audio
Realtek ALC883 8-Channel HD Audio CODEC w SPIF in and out

Ethernet LAN
Realtek RTL8211B PHY Gigabit Ethernet LAN
Realtek RTL8111C PCI-E Gigabit Ethernet LAN

USB
Embedded 10 * USB 2.0/1.1

Special Features
Advanced Power Design that supports the latest Socket-AM2+ CPU
"IMAGE IT!"System Backup Software and "ProMagicPLUS!" System Recovery System

Rear Panel I / O
6 * USB 2.0/1.1 ports
1 * PS/2 Mouse & Keyboard Combined connector
2 * RJ-45 ports
2 * Audio I / O ports
1 * VGA port
1 * DVI port
2 * DB-9 RS232 ports

Internal I / O
2 * USB 2.0/1.1 headers for 4 USB 2.0 ports
CPU / Chassis Fan connectors;
1 * 4-pin ATX 12V Power connector and 1 * 20-pin ATX Power connector
CD / AUX Audio in&1 * Serial Port header

BIOS
Award 8MB SPI Flash ROM

Form Factor
Mini ITX Form Factor(17cmx17cm)



Intel® Desktop Board DG45FC (Flying Creek)



Form factor Mini-ITX (6.70 inches by 6.70 inches [171.45 millimeters by 171.45 millimeters])

Processor Click view supported processors for the most current list of compatible processors.

At product launch, this desktop board supports:

Support for an Intel® Core™2 Duo processor in an LGA775 socket
Support for an Intel® Pentium® dual-core processor in an LGA775 socket
Support for an Intel® Celeron® dual-core processor in an LGA775 socket
Support for an Celeron® processor 400 sequence in an LGA775 socket

Memory Two 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
Support for DDR2 800/667/533 MHz DIMMs
Support for up to 4 GB of system memory

Chipset Intel® G45 Express Chipset

Audio Intel® High Definition Audio in the following configuration:

8-channel (7.1) audio subsystem with five analog audio outputs and one optical S/PDIF digital audio output using the IDT 92HD73E audio codec

Video Intel® Graphics Media Accelerator X4500HD onboard graphics subsystem with integrated HDMI + DVI-I display ports

LAN support Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel® 82567LF Gigabit Ethernet Controller

Peripheral interfaces One serial port via header
Up to 10 USB 2.0 ports (6 back ports and 4 via headers)
5 Serial ATA 3.0 Gb/s ports, including 1 eSATA back port with RAID 0, 1, 5, 10 support
Consumer IR receiver and emitter (via internal)

Expansion capabilities One PCI Express* x1 bus add-in card connectors


J&W 780G - SP128M







"
The J&W 780G-SP128M mobo.
J&W may not be the first motherboard manufacturer that comes to mind, but it has managed to scoop out a niche 780G mini-ITX board with its iPartner "Control Centre" that sits outside the case.

The iPartner features a power and reset button, as well as an eight digital LCD readout and Bluetooth built in - this allows you to connect a wireless keyboard or mouse directly to it, which is perfect for kicking back on the sofa and controlling your HTPC remotely.

The board features DVI, HDMI and VGA, both types of S/PDIF out, eSATA, four SATA, plenty of USB, Gigabit Ethernet and all solid aluminium capacitors. Most notably though it's the only 780G we've yet seen that has a 128MB frame buffer for extra GPU performance, although there's even a PCI-Express x16 slot if you want some serious graphic horsepower.

Both the north and south bridges are passively cooled by the same heatsink, and even the CPU PWMs get some heatsinking too - none of it was hot to touch as it played back a HD movie.

The only downside of this board was the fact you have to use SO-DIMMs, however it would be physically impossible to use DIMM slots and SO-DIMMs aren't that expensive, plus, you really don't even need dual channel for HTPC boards and general productivity."


Che ne dite? Oltreoceano "sconsigliano" in generale l'Intel per una questioe di Driver, che non è molto reattiva a rilasciarli e fare correzioni.
La J&W, mi fido poco.... mi intriga la 780G...


ciao ciao

Alex

[essemme]

Ottime info!

ma la NC 81 si trova a giro anche online? io non riesco.

Ormai con queste schede ci si possono fare dei potenti PC
